How to Calculate Cone Distance?
Cone Distance calculator uses Cone_Distance = sqrt(((Pitch circle diameter of pinion/2)^2)+((Pitch circle diameter of gear/2)^2)) to calculate the Cone distance, Cone distance is the length of the pitch-cone element. It is also called pitch-cone radius. It is denoted by A0. Cone distance is denoted by A_{0} symbol.
How to calculate Cone Distance using this online calculator? To use this online calculator for Cone Distance, enter Pitch circle diameter of pinion (D_{p}) & Pitch circle diameter of gear (D_{g}) and hit the calculate button. Here is how the Cone Distance calculation can be explained with given input values -> 72.11103 = sqrt(((0.08/2)^2)+((0.12/2)^2)).
